trioBike

Lead time at the moment: 8 weeks

Bosse mid-drive will be available from September 2018.

The seat box is a beautiful, state-of-the-art unit made of beechwood by a German furniture manufacturer. Hood and blanket are made of solid weather-proof material, and an insert in the footrest makes it easier for passengers to get on board.

Prices

5,805 EUR (250W) ex works (5,600 EUR before 14 April)
6,235 EUR (500W) ex works (6,030 EUR before 14 April)

25% VAT is added to all orders in the European Union, except for companies with a valid EU VAT number.

All the tech stuff

E-power system by Promovec

TrioBike uses the e-power system on their bikes and trikes.

The Danish brand Promovec is acknowledged for being one of the most reliable e-power systems on the market. The system is tested in extreme conditions, both under hot and cold conditions, which makes it extremely usable in any weather. The range of the battery is up to 30 km on a fully loaded trike and 60 km on a regular bike per charging.

Specifications

Motor – 250 and 500 Watts
Battery – Li-on / 36V / 13.6 Ah / 490 Wh
Assist levels – 4 levels
Nom 40 Nm
Wheel Sizes – 26” (hydraulic disc brake)
Walk assist from 0-6 km/h – Throttle to activate e-power system

Headset: VP-A45AC
Bottom bracket: CH-52 ENC 68x118mm BSA
Rim: Alexrims DM24 20”
Handlebar: MTB-AL-345BT 31.8mm
Crankset: Lasco 170mm
Pedal: Wellgo M095
Front brake: Tektro Auriga Twin HD-T525
Rear brake caliber: Shimano BR-M395
Brake lever: Shimano BL-M396
Derailleur: Shimano Deore
Shifters: Shimano Deore
Grips: Ergo Grip
Saddle: Velo VL-3061G
Lock: AXA/Basta Solid

Length: 225 cm
Width: 106 cm
Height: 113 cm

Weight: 53 kg

Max payload on the front box: 160 kg
Overall max payload: 250 kg

Warranty

TrioBike A/S guarantees that your product is without errors in the materials, shape and functionality at the time of purchase. You are covered by a 2 year warranty. 5 years warranty on the frame. The warranty is valid with showing the original invoice. The following items are not covered by the guarantee: Tires, sprockets, tubes, chain and rims.

Should a fault occur in the product within the warranty period of two years – and if the fault is not due to irresponsible handling of the product by you – the warranty is your safety for a quick assistance free of charge. Bring your invoice and proof of payment when you contact Copenhagen Cycles.

Triobike A/S reserves the right to deny carrying out the warranty, if information on the invoice have been removed or changed. The warranty only applies for errors in the material, shape/design or functionality.

The warranty does not cover periodic control and inspection, repairs or changing of spare parts that have been destroyed due to wrong use or handling of the bicycle.

This warranty does not influence on your legal rights. If no legal law is relevant, your rights are restricted to the contents in the warranty.

Please see the Triobike manual for further details on warranty. If you experience any faults with the bike, please fill out our Warranty Claim form via our website before fixing the damage if you believe its under the warranty.

Service

When you purchase a new trioBike, we recommend that you have it serviced after 3 months of use. Afterwards service once a year. trioBikes consist of parts used for regular bikes that most bike shops have. You must make sure that their staff is professional and knows how to service a trioBike. Because of wear and tear parts will eventually have to be replaced.

Frame number

You can find the frame number on the frame, in front of the right front wheel, below the tree box module. It starts with WTRIO with 4 following digits and a letter.

Order here

Download the trioBike taxi manual
